ASC-350D
Auto Sheet Cutter
🆕 ASC-350 Series Auto Sheet Cutter
The ASC-350 series delivers high-speed and stable performance through its advanced servo motor system, while ensuring precise output through accurate registration mark detection via a built-in camera and contour cutting system.
ASC-350D
DSC_5174
ASC-350
1 1
Auto Sheet Cutter
🆕 ASC-350 Series Auto Sheet Cutter
ASC-350 series is designed to handle a wide range of production needs, from labels and stickers to customized cards and packaging mockups.
INQUIRY
Print

ASC-350 / ASC-350D Auto Sheet Cutter Feature

Versatile Cutting Aplication

Supports die cutting, kiss cutting, and perforation to meet various application needs.

Barcode Recognition & Direction Correction

Built-in camera for contour cutting and registration alignment.

High-Volume Sheet Capacity

Media capacity up to 40 mm in total thickness, approximately 150 sheets.

Maximize Material Usage

Dual-row pinch rollers provide stable feeding and improve media edge utilization.

Professional Creasing

Rotary wheel creasing for precise fold lines. Available on ASC-350D only

4” Touch Panel

The 4-inch touch screen provides an intuitive and user-friendly interface

ASC-350 / ASC-350D Auto Sheet Cutter Spec

ModelASC-350ASC-350D
Key Features．High-Speed Cutting
．Perforation Cutting		．Rotary Wheel Creasing.
．Box Sample Making
．Supports Full Cut and Half Cut
Max. Media Width370 mm
Max. Cutting Width350 mm
Max. Media Thickness0.8 mm (approx. 600 ~ 700 gsm)
Max. Media Length600 mm
Media Tray CapacityUp to 40 mm stack height
(approx. 100 sheets of 300 gsm cardstock*1)
Auto Contour CutCamera (Automatically Contour Cutting)
ControlTouchscreen
MotorServo motor
Max. Force1500 gL: 3000 g / R: 1500 g
Number of Heads12
Cutting Precision±0.01 mm
Repeat Precision0.082 mm
Max. Empty Running Speed1600 mm/S
Max. Cutting Speed1600 mm/S
Power Supply100-240 VAC, 50–60 Hz, Auto-Switching, Max. 15 A
Power Consumption1500 W ~ 3600 W
Packing Size890 x 570 x 560 mm940 x 610 x 580 mm
Gross49.5 kg56.5 kg
Connector InterfaceUSB A (flash disk) / Wi-Fi (option) / USB B (connection) / Ethernet
Operating Temperature+5 °C to +35 °C
Operating Humidity40 to 60 % RH (non-condensing)
  • *1: Actual capacity may vary depending on media type and thickness.
  • The specification and data sheet may vary with different materials used. In order to obtain the best output quality, please maintain the machine regularly and properly.
  • GCC reserves the right to change the specifications at any time without notice.
  • The above listed specification values are effective only when operated with media certified by GCC.
